Custom Leak Sealing Enclosures for Substations

A wall leak in substation equipment should be assessed as an equipment-specific leak rather than treated with a general building sealant. TDS evaluates the apparatus and leaking component, then selects a compatible low-pressure sealing method. For drain plugs, valves, and related areas, an enclosure or clamp can contain sealant around the leak while preserving access for future removal.

Substation equipment leaks should not be addressed with an unverified instant water-leak product. Transformer oil, SF6 gas, and electrical apparatus require compatible materials and controlled repair methods. TDS’s product information identifies a non-adhering rubber-based sealant for its drain plug enclosures and clamps, with suitability determined by the equipment and leak conditions.

The enclosures and clamps are intended for drain plug and valve leak applications across substation apparatus. Listed use cases include transformer radiator bank drain plug leaks, transformer tap changer compartment drain plug leaks, oil-filled circuit breaker drain valve leaks, and electric substation apparatus leak sealing. Final suitability should be confirmed from the equipment configuration and leak location.

The product information states that the enclosure can be installed with equipment energised and online. Actual installation depends on the apparatus, leak location, site conditions, and applicable safety procedures. TDS personnel should evaluate the application before work begins to confirm whether an online installation is appropriate for the specific substation equipment.

The listed design can eliminate the need to drain oil from radiator banks or compartments for applicable drain plug leak repairs. It is also removable without permanent modification. Whether oil draining can be avoided depends on the equipment arrangement and exact leak location, so the application should be reviewed before selecting the repair method.

The custom aluminum enclosure is held in place by two set screws and crunch teeth. After positioning, the void is pumped with a non-adhering rubber-based sealant intended for the leak-sealing application. This design provides a targeted, removable repair for common drain plug sizes while avoiding permanent modification to the equipment.
